565-003-714-900, EDAC Black 1m Telephone Extension Cable 3 Way Male Wire to Wire

IP67 Cable Plugs and Sockets, 3A

Pre-terminated IP67 connectors, wire-to-wire with 1m of wire. Latch mechanism prevents misalignment and unintentional disconnection Lightweight, high impact, flame retardant (UL94-VO) PBT housings

Suitable for wire-to-wire connection up to 3A
Tin-plated phosphor-bronze contacts
Insulator withstand voltage: 100Va.c.
Rated Voltage: 250Va.c.
Silicone rubber wire housing seal
Contact resistance: 10mΩ max.
Insulation resistance: 1000MΩ @ 500Vd.c.
Temperature range: -40°C to +105°C
Mating life cycles: 100 min.

IP67 Edac Range

565 Series Waterproof Connector Data Sheet
