N2526-6003RB, 3M, 2500, 26 Way, 2 Row, Straight PCB Header

7494708
Номер производителя: N2526-6003RBПроизводитель: 3M
Цена за шт.
597.00 руб. (С НДС) *

Срок поставки: 4-6 недель

+

* УТОЧНЯЙТЕ ВОЗМОЖНОСТЬ, ЦЕНУ И СРОК ПОСТАВКИ, В СВЯЗИ С ОГРАНИЧЕНИЕМ ЭКСПОРТА ТОВАРОВ ИЗ СТРАН ЕС И ВЕЛИКОБРИТАНИИ

3M 2500 Series 2.54 x 2.54mm Low Profile Four-Wall Shrouded PCB Headers

2500 series 2.54 x 2.54mm four-wall shrouded PCB headers with a low profile, space saving design available in SMT, through hole, straight and right angle PCB mounting configurations. These 2.54mm 2500 series PCB headers have centre slot polarization to facilitate accurate insertion and dual slot polarization making the connector compatible with other competitive polarization designs. Versions of these 2500 series PCB header connectors are available with a high temperature (260°C) black PCT housing (part numbers pre-fixed with 'N') which are suitable for 'no lead' soldering operations, through hole PCB headers with high temperature housings are suitable for 'paste in hole' reflow soldering techniques.
Part numbers (N)25xx-xx02 are for use with a 1.57mm PCB thickness
Part numbers (N)25xx-xx03 are for use with a 2.39 to 3.18mm PCB thickness
A latch is available for use with these headers see stock number 192-7782
Socket retainer clips are also available for these shrouded PCB headers, see stock number 323-8220 typically

Техническая спецификация
pdfFour‑Wall Header 2500 Series
Защищенный/Незащищенный:
Shrouded
Кол-во контактов:
26
Количество рядов:
2
Концевая заделка:
Припой
Материал контактов:
Медный сплав
Номинал тока:
5.0A
Ориентация корпуса:
Прямой
Покрытие контактов:
Золото
Серия:
2500
Система соединителя:
Board to Board, Wire to Board
Тип монтажа:
Сквозное отверстие
Шаг:
2.54мм
