ST1000SPEX2L PCIe Network Card

The ST1000SPEX2L Low-Profile PCIe Gigabit Network Card adds a 10/100/1000 Mbps compatible RJ45 Ethernet port to a PCI Express-enabled client, server or workstation, providing a convenient addition or replacement networking interface.

Compliant with IEEE 802.3/u/ab standards, and with support for 9K Jumbo Frames, VLAN tagging and Wake on LAN (WOL), this versatile Gigabit NIC/Server Adapter offers effective network performance.

The card comes pre-configured with a low-profile/half-height installation bracket and includes a standard profile bracket for installation in a wide range of computer/server chassis, regardless of form factor.

Backed by a 2-year StarTech.com warranty and free lifetime technical support.

Features & Benefits

• A single 10/100/1000Mbps compatible RJ45 Ethernet port
• Gigabit detection and Link/Activity LED indicators
• Fully Compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3x and IEEE 802.3ab standards
• Supports IEEE 802.1Q VLAN tagging, IEEE 802.1P Layer 2 Priority Encoding and IEEE 802.3x Full Duplex Flow Control
• Jumbo frame support
• Full and half duplex support
• Supports Wake-on-LAN function
• Crossover Detection &
Auto-Correction (Auto MDI/MDI-X)
• Optimize network traffic with support for advanced features such as Jumbo Frames and VLAN tagging
• Saves the time of having to adjust the mounting bracket, with a pre-configured half-height/low-profile bracket

Applications

• Upgrade from 10/100 Ethernet capability to Gigabit capability
• Add an Ethernet port to a workstation or server computer, for redundancy or bridging
• Add networking capabilities to an old system with no Ethernet port

What’s in the package?

• Gigabit Ethernet PCI Express Card
• Standard Profile Bracket
• Driver CD
• Instruction Manual
