1990850, Phoenix Contact SPT 1.5/ 2-V-3.5 Series PCB Terminal Block, 2-Contact, 3.5mm Pitch, Through Hole Mount, 1-Row, Spring

0112308
Номер производителя: 1990850Производитель: Phoenix Contact
Цена за шт. (норма упаковки 5 шт)
301.00 руб. (С НДС) *

Срок поставки: 4-6 недель

+

* УТОЧНЯЙТЕ ВОЗМОЖНОСТЬ, ЦЕНУ И СРОК ПОСТАВКИ, В СВЯЗИ С ОГРАНИЧЕНИЕМ ЭКСПОРТА ТОВАРОВ ИЗ СТРАН ЕС И ВЕЛИКОБРИТАНИИ

Phoenix Contact COMBICON SPT 3.5mm PCB Terminal Blocks

Print terminals with front spring loaded connection
Solder pins for high stability on the printed circuit board
Plug-and-play technology for rigid or flexible cables with ferrule
For flexible cables without ferrules — open terminal compartment with screwdriver
Connect vertically (V) or horizontally (H)
3.5 and 5 mm grid can be used together

Approvals

UL, CUL

Phoenix Contact 2-pin PCB Terminal Strip, 3.5 mm Pitch - SPT 1.5/ 2-V-3.5 - 1990850

This Phoenix Contact 2-pin terminal strip is a simple and effective way to connect two wires to a printed circuit board (PCB). It's designed for boards with a pitch (distance between solder balls) of 3.5 mm.
Installation is straightforward thanks to a push-in connection method that doesn't call for any specialist tools. Dual solder pins also help to reduce the mechanical strain on the soldering spots and a defined contact force ensures stability over the long term. Phoenix Contact's innovative spring cage termination method makes connections simple, secure and resistant to vibration.
This terminal strip is a flexible option as it can fit vertically or horizontally, depending on the configuration of your PCP. Its compact design saves space and is suitable for a wide variety of applications, even in harsh industrial environments.

• Straight body orientation
• Through-hole mounting type
• Dimensions of 8.4 (length) x 14.4 (width) x 13.5 mm (depth)
• Pitch of 3.5 mm
• Current rating of 17.5 A
• Voltage rating of 160 V
• Single row
• 2 contacts

Approvals

UL, CUL

Техническая спецификация
pdfSpring-cage PCB termination block SPT 1,5/ 2-V-3,5
Глубина:
13.5мм
Длина:
8.4мм
Кол-во контактов:
2
Количество рядов:
1
Концевая заделка:
Spring Cage
Номинал тока:
17.5A
Номинальное напряжение:
160 В
Ориентация корпуса:
Прямой
Серия:
SPT 1.5/ 2-V-3.5
Тип:
PCB Terminal Block
Тип монтажа:
Сквозное отверстие
Шаг:
3.5мм
Ширина:
14.4мм
