1990892, Phoenix Contact SPT 1.5/6-V-3.5 Series PCB Terminal Block, 6-Contact, 3.5mm Pitch, Through Hole Mount, 1-Row, Spring

0112415
Номер производителя: 1990892Производитель: Phoenix Contact
Цена за шт. (норма упаковки 5 шт)
878.50 руб. (С НДС) *

Срок поставки: 4-6 недель

+

* УТОЧНЯЙТЕ ВОЗМОЖНОСТЬ, ЦЕНУ И СРОК ПОСТАВКИ, В СВЯЗИ С ОГРАНИЧЕНИЕМ ЭКСПОРТА ТОВАРОВ ИЗ СТРАН ЕС И ВЕЛИКОБРИТАНИИ

Phoenix Contact COMBICON SPT 3.5mm PCB Terminal Blocks

Print terminals with front spring loaded connection
Solder pins for high stability on the printed circuit board
Plug-and-play technology for rigid or flexible cables with ferrule
For flexible cables without ferrules — open terminal compartment with screwdriver
Connect vertically (V) or horizontally (H)
3.5 and 5 mm grid can be used together

Approvals

UL, CUL

Phoenix Contact Spring-cage PCB Termination Block, 3.5 mm Pitch - SPT 1,5/ 6-V-3,5 - 1990892

Easily transmit power and data directly to your PCB (printed circuit board) with this terminal block from Phoenix Contact. It has six spring-loaded connectors to allow for quick, tool-free wiring, and it accepts conductors either vertically or horizontally.
The unit's patented spring-cage technology is compatible with both rigid and flexible cables with ferrules. It can be used with unguarded wires that are attached by opening the terminal compartment with a screwdriver. Solder pins hold it securely to your PCB. The signature green-coloured housing is made of high-strength plastic that's recyclable, halogen-free and resistant to UV (ultraviolet) light. It also has a UL (Underwriter Laboratories) 94 V-0 rating due to its low flammability.
This compact connection block is suitable for a broad range of applications across industry and commerce. It's a safe and effective solution for when you want to support and insulate wire terminations and joints permanently.

• Voltage rating of 160 V
• Current rating of 17.5 A
• Straight body orientation
• Through-hole mounting type
• Spring-cage termination method
• Single row
• Pitch of 3.5 mm
• Dimensions of 22.4 (length) x 14.4 (width) x 13.5 mm (depth)

Approvals

UL, CUL

Техническая спецификация
pdfSpring-cage PCB termination block SPT 1,5/ 6-V-3,5
pdfDatasheet - 1990892
pdfDimension Sheet - 1990892
pdfCatalogue - Terminal Block
Глубина:
14.4мм
Длина:
13.5мм
Кол-во контактов:
6
Количество рядов:
1
Концевая заделка:
Spring Cage
Материал:
PA (Insulate)
Номинал тока:
17.5A
Номинальное напряжение:
200 В
Ориентация корпуса:
Вертикальный
Серия:
SPT 1.5/6-V-3.5
Тип:
PCB Terminal Block
Тип монтажа:
Сквозное отверстие
Цвет:
Зеленый
Шаг:
3.5мм
Ширина:
22.4мм
