MA2062-HVL.GN, Sunon MA Series Axial Fan, 230 V ac, AC Operation, 30.6m³/h, 4.4W, 211mA Max, 60 x 60 x 25mm, Вентилятор

0126183
Номер производителя: MA2062-HVL.GNПроизводитель: Sunon
Цена за шт.
6737.50 руб. (С НДС) *

Срок поставки: 4-6 недель

+

* УТОЧНЯЙТЕ ВОЗМОЖНОСТЬ, ЦЕНУ И СРОК ПОСТАВКИ, В СВЯЗИ С ОГРАНИЧЕНИЕМ ЭКСПОРТА ТОВАРОВ ИЗ СТРАН ЕС И ВЕЛИКОБРИТАНИИ

Sunon Maglev AC Axial Fan

The Sunon Maglev AC axial fan is 60mm x 60mm x 25mm in size. It has a supply voltage rating of ranging between 220VAC to 240VAC. This fan has 4200rpm motor speed. It uses maglev-powered technology, which enables fault-free use for a significant period of time. It also ensures that AC fans provide a flexible and dependable cooling solution for applications that require a fan to be mounted in any axial position. This fan has a power consumption rating of 4.4W. This power series AC fans utilise maglev technology to produce a fan with superior performance, low noise and long-life. It achieves this zero friction through no contact between shaft and bearing. With excellent rotational stability, this fan eliminates vibration, typical wobble and shaking experienced in fan motors. It also provides excellent high-temperature endurance that results in a long-life. Additionally, these fans also feature all-plastic manufacture of major items for optimal insulation resistance and electrostatic discharge (ESD) performance. These power series also feature two innovations to further enhance the performance and life span.

Features and Benefits

Extended motor life
Prevention of oil leakage
High-quality construction
High efficiency and high performance
Outstanding airflow/size ratio

Applications

Domestic appliances
Enclosures
Fans, motors and pumps
Heating and ventilation
Industrial drives
Instruments
Machines in industries
Medical field
Power supplies
Printing

Certifications

UL approved
CE certified

Техническая спецификация
pdfDatasheet
