NC3MXX, Neutrik Cable Mount XLR Connector, Male, 50 V, 3 Way, Silver Plating, Разъем

Neutrik XLR Connector

The Neutrik 3-contacts dis-assembled male XLR connector has a voltage rating of 50V and a current rating of 16A. This connector has a silver over nickel plating. It offers several new features which make it more reliable, easier to assemble and improves contact integrity as well cable strain relief.
Warning:
Not to be used as mains connectors
Product application information:
Whether in the studio or on the stage, XLR connectors are a recognised standard for microphone and PA connections. They also have further applications in video and lighting systems. An XLR connector is expected to provide a dependable connection in busy environments. The durability and quality of a connector is a top priority for people in professional audio and stage management roles.

Features and Benefits

Boot with polyurethane gland gives high protection to cable bending stresses
Branded with a unique hologram guarantees genuine and authentic Neutrik product
Coloured rings and boots available for coding or identification
Improved chuck type strain relief provides higher pull-out force and makes assembly easier and faster
Internal thread on shell is well protected against any damage
Male connector with improved locking recess without "window", more stringent housing increases durability
Operating temperature ranges between -30°C and 80°C
Sleek and ergonomic design that is handy

Certifications

UL approved

XLR Switch Range Product Guide

Assembly Instruction

Technical Drawing

NC3MXX Datasheet
