1031400000, Weidmuller WDU Series Brown Feed Through Terminal Block, 1.5mm², Single-Level, Screw Termination

Weidmuller Feed-Through Terminal Block, Screw Connection Type, 23A Current Rating - W Series - 1031400000

Need a reliable link between cables and your DIN rail-connected equipment? This feed-through terminal block from Weidmuller is just the thing. Thanks to its insulated Wemid housing, it provides a safe path for electrical signal transmission between machines. This reduces the risk of electrical hazards, helping to keep you and your equipment safe and sound. A current rating of 23A makes this component a dependable choice for heavy-duty applications. Snap-on DIN rail mounting means you don't need any tools, so you can install it in a jiffy.

Features & Benefits

• Stops burning in 10 seconds or less for safety in the event of a fire
• Wide operating temperature range between -60°C and +130°C for use in challenging conditions
• Tightening torque of 0.4Nm for a secure hold on connected cables
• Rated impulse withstand voltage of 8kV for electrical safety

Applications

• Telecommunications industry
• Industrial lighting
• HVAC systems

What are the dimensions of this terminal block?

This unit has compact dimensions of 60 (L) x 5.1 (W) x 46.5mm (H), making it a space-efficient solution for confined setups.

Approvals

VDE; IEC 947-7-1

The ’W’ series screw clamp terminals are suitable for ’Top Hat’ DIN Rail and manufactured from nylon 6.6 which has a continuous temperature rating of 120°C (180°C short term). They are self-extinguishing to UL94V-0 and free from cadmium and halogen. Current bars are constructed from 10 mm electrolytic copper to ensure a current loading more than nominal rating. Terminals are suitable for mounting on symmetric ’Top Hat’ rail only (BS5584:1978, EN 50022) and are touch proof in accordance with BS 3042.
