ESC18150-S-1IP, Ideal Power ESC 30W Isolated DC-DC Converter Through Hole, Voltage in 9 → 36 V dc, Voltage out 15V dc, Преобразователь

0248265
Номер производителя: ESC18150-S-1IPПроизводитель: Ideal Power
Цена за шт.
57297.00 руб. (С НДС) *
Количество 5+ 10+ 25+ 50+
Цена 54432.00 руб. 51567.00 руб. 48702.00 руб. 45837.00 руб.

Срок поставки: 4-6 недель

+

* УТОЧНЯЙТЕ ВОЗМОЖНОСТЬ, ЦЕНУ И СРОК ПОСТАВКИ, В СВЯЗИ С ОГРАНИЧЕНИЕМ ЭКСПОРТА ТОВАРОВ ИЗ СТРАН ЕС И ВЕЛИКОБРИТАНИИ

Ideal Power 30W Single/Dual Output Regulated Isolated DC-DC Converter - ESC Series

50.8x30.5x8.9 mm metal package (2.0x1.2 inch)
Ultra-wide 4:1 input voltage range (except ±24V)
Very high efficiency up to 88%
1.5kV input / output isolation
Built-in filter meets EN 55022, Class B and FCC Level B without external components
Adjustable output voltage via external resistor (±5%, single O/P types only)
Remote On/Off Control
Input under-voltage lockout with auto turn-on
Over-voltage and over-temperature protection
Output current limit and continuous short circuit protection
Shielded metal case with insulated baseplate
Industry standard pin-out
MTBF > 1.9million hours to Bellcore TR-332 @ 50°C

Note

Operating temperature 100% load, Free Air, No derating, Maximum case temperature 100°C (dependent upon model).
Dual output models can be used as single outputs (24V/30V/48V) depending on model.

Standards

UL 60950-1, EN 60950-1, IEC 60950-1 (Compliance up to 60 VDC input voltage, SELV limit)\t

Approvals

UL,TUV

Техническая спецификация
pdf30W DC/DC CONVERTER ESC SERIES Data Sheet
pdf30W DC/DC ESC CONVERTER SERIES Application Notes
Выходной ток:
2A
Глубина:
9.4мм
Диапазон входного напряжения:
9 → 36 В пост. тока
Длина:
50.8мм
Количество выходов:
1
Максимальная температура:
+100°C
Минимальная температура:
-40°C
Мощность номинальная:
30Вт
Напряжение выходное:
15В пост. тока
Напряжение изоляции:
1.5кВ пост. тока
Номинальное входное напряжение:
18 В пост. тока
Серия:
ESC
Тип монтажа:
Сквозное отверстие
