LS2D4L, Honeywell HDLS Series Plunger Limit Switch, 2NO/2NC, DPDT, Stainless Steel Housing, 600V ac Max, 10A Max

HDSL Stainless Steel Limit Switches

These switches are designed for use in highly corrosive environments such as petrochemical plants, food processing plants, shipboard, and dockside locations. The type 316 cast stainless steel body is designed to minimize crevices where particles could become trapped. The actuator, operating head, and screws are also stainless steel. All seals are fluorocarbon to provide excellent chemical resistance and to withstand operating temperatures up to 121°C (250°F) and pressurised steam cleaning. Preleaded and epoxy filled versions are also available. Interchangeable with standard HDLS mounting.

Corrosion-resistant stainless steel non-plug in body, head and rotary shaft
Stainless steel levers
Fluorocarbon seals
Operating temperature range –12°C to +121°C (10°F to +250°F)

Standards

UL Listed, file E37138. CSA Certified, file LR57326

Approvals

NEMA 1, 3, 3R, 4 4X, 6, 6P, and 13

Approvals

UL, CSA.
