G7L-2A-T AC100/120, Omron Panel Mount Power Relay, 240V ac Coil, 25A Switching Current, DPST, Реле

PCB Mounting & Plug-in - Power Relays - G7L Series

Relay compatible with momentary voltage drops up to 50% of rated voltage
High capacity and high dielectric strength
Flame-resistance UL94V-0 insulation material
Choice of connection types available - quick-connect or PCB terminals
Suitable DIN rail/surface socket (Front connecting socket) and relay mounting clip (E-bracket) available separately for use with quick-connect types G7L-1A-T and G7L-2A-T (not to be used with G7L-1A-TUB and G7L-2A-TUB upper bracket mount types)

Approvals

UL; CSA; TÜV

OMRON Power Relay, 4-Pin Connector Type, 120V AC Coil Voltage Rating - G7L Series - G7L-2A-T AC100/120

Want an automated system that ticks over without your help? Put this OMRON power relay in charge. Signals from your control unit tell it when to switch its contacts, meaning you get hassle-free remote switching in applications like material handling and packaging systems. As it has highly conductive silver alloy contacts, the unit keeps electricity flowing efficiently. A double-pole construction means it conveniently manages two circuits at once. You won't be left waiting by this relay, which has a 30ms response time.

Features & Benefits

• Panel mounting style for straightforward installation
• Electrical service life of over 100,000 cycles for long-lasting switching
• Switches loads up to 25A to handle standard currents
• Plastic insulation cuts user exposure to dangerous loads
• Dimensions of 52.5 (L) x 53 (W) x 33.5mm (D) fit easily into busy setups

Applications

• Manufacturing industry
• HVAC systems
• Fluid management

Can the product handle fast-paced applications?

Yes, this relay can complete up to 1800 switching cycles an hour to keep up with demanding stop/start processes.

Can I run this device on battery power?

Yes, the unit uses up to 2.5VA, ensuring you get efficient switching with battery-powered equipment.
