RS PRO Plug In Power Relay, 24V dc Coil, 10A Switching Current, 3PDT, Реле

10A Industrial Relay

Protected by a clear polycarbonate cover
DIN Rail or Surface Mounting
Contact Material: Ag + Au Flashed
Contact Rating is 10A
Maximum switching voltage 250 Vac, 30 Vdc
Mechanical Life of 10⁷ Operations (min)
Electrical Life of 10⁵ Operations (min)
Maximum temperature at rated coil voltage 65°C
Dimensions: H 53mm, W 36mm, D 36mm

RS PRO 10 A 3 PDT Non-Latching Relay

Innovation brings new solutions and makes life more comfortable for us all. An electrical switching device is one of them to appreciate from Automotive engines, industrial machinery to more tangible in household applications, regardless whether it is latching or non-latching Relay. They both represent a different approach to application functionality, bringing your electronics world to life.

Today, we are proudly introducing our own branded RS PRO 3 PDT Relay giving you protection by a transparent polycarbonate cover. Relay rating is showing in ac and dc, and it is crucial never to exceed the maximum switching voltage. Our 3 PDT (Contact Configuration) Relay provides 240 V ac and 30 V dc telling you about the specific amount of power that can be switched through the Relays.

The characteristic click sound indicates the movement of the terminal, which is typical for mechanical Relays. The centre of a Relay is a coil of wire which is powered by AC or DC current. Our non-latching DPDT Relay has a closed position (NC) unless power passes through the circuit, then the Relay opens (NO) part by using an internal coil to generate a magnetic force.

Our range of Non-Latching Relays are reliable, well-respected electronics, offering you competitive price range without compromising quality and you can be sure to find them in stock. If you are looking for more specific information, you can check our datasheet that should answer your burning questions.

Features and Benefits

• The A transparent polycarbonate cover protects DPDT


• DIN Rail or Surface Mounting


• Contact Material: Ag + Au Flashed


• Contact Rating is 10A


• Maximum switching voltage 240 Vac, 30 Vdc


• Mechanical Life of 107 Operations (min)


• Electrical Life of 105 Operations (min)


• The maximum temperature at the rated coil voltage of 65°C


• The minimum operating temperature of -45°C


• DPDT dimensions are Height 56 mm, Width 35 mm, Depth 35 mm

Applications

Terminal compact size and reliable mechanism of the Relay Circuit has its place in the following applications:

• Automotive engines


• Household applications


• Industrial machinery


• Medical equipment


• Telecommunications equipment

Frequently asked questions

What is the difference between latching and non-latching relays?

Both types of relays in similar in design and function; however, a significant difference between them is that a latching relay will remain in the last position when it was last powered. In contrast, a non-latching goes back to its normal position. This makes each more type of Relay suitable for different applications.

Does it make much difference which way a Relay is installed?

If the coil polarity is backwards, the coil is ultimately shorted by the diode every single time you try to turn it on. Therefore, Relays must always have the correct position (correct polarity); otherwise, it is a matter of time before smoke will appear, meaning Relays are polarity sensitive.

Why RS PRO?

RS PRO is our family brand to go-to and brings you a wide range for high-quality and high-value products to support your project. Trusted by engineers all over the world, every part of every RS PRO product is always rigorously tested against demanding industry standards. We are only giving the RS PRO seal of approval if we are confident of their exceptional quality, which means you can be convinced too.
