5SM3646-6KL, Siemens 4 Pole Type A Residual Current Circuit Breaker, 63A 5SM3, 300mA, Автоматический выключатель

5SM3 Series, Undelayed Type A, 4-pole, Left-Side N Connection

RCCB for alternating and pulsating DC residual currents
Option for power connection from above or below
Tunnel terminals with wire protection on both sides
Combination terminal at the bottom for simultaneous connection of busbars and conductors
Safe for fingers and overhands according to DIN EN 50274 (VDE 0660 part 514)
Mounts to DIN rail (TH 35 to DIN EN 60715)
Behind-panel depth 70 mm

Standards

IEC/EN 61008-1, IEC/EN 61008-2-1, IEC/EN 61543

Approvals

VDE 0664-10, VDE 0664-11, VDE 0664-30

Approvals

VDE 0664-10, VDE 0664-11, VDE 0664-30

Standards

IEC/EN 61008-1, IEC/EN 61008-2-1, IEC/EN 61543

Siemens FI circuit breaker

RCCB Type A, N-Left 63A 3+Npole Ifn 300M
