9502600000, Weidmuller SAKK Series Brown Modular Terminal Block, 4mm², Single-Level, Screw Termination, ATEX, IECEx

Weidmuller Modular Terminal Block, Ceramic Body Material, Screw Connection - SAKK Series - 9502600000

Looking for a control solution for your electrical systems that can perform in the heat of the moment? Choose this modular terminal block from Weidmuller. Its ceramic housing has excellent heat resistance and can handle temperatures as high as +250°C, making it a reliable partner in demanding conditions. As it stops burning in 10 seconds or less when a fire occurs, it's a safe option for use in sensitive work areas. Thanks to its voltage rating of 800V, you can depend on this piece of kit in heavy-duty applications.

Features & Benefits

• Current rating of 32A for use in high-current applications
• Compact dimensions of 40 (H) x 8 (W) x 53mm (D) for installation in tight spaces
• Screw connections for secure wiring
• Open side panel for easy integration with other terminal blocks

Applications

• Automotive manufacturing
• Process and packaging equipment

How do I mount this terminal block?

This terminal block is designed for direct mounting onto your DIN rail. The process is simple and needs no tools, saving you time and effort.

Approvals

1, 2

SAK Series

Terminals manufactured from polymide 6.6 with a working temperature of -50°C to +100°C except the fused terminal block (425-689) which is high grade melamine with a working temperature of -60°C to +130°C. Asymmetric rail (G-profile) to B 5825:1980 EN 50035 mounting

SAKK4 Connector Data Sheet

SAK Series Data Sheet

0454615_Catalogue
