192991-0254, ITT Cannon, 24 Way, 4 Row, Straight Backplane Connector

0466933
Номер производителя: 192991-0254Производитель: ITT Cannon
Цена за шт.
3474.00 руб. (С НДС) *

Срок поставки: 4-6 недель

+

* УТОЧНЯЙТЕ ВОЗМОЖНОСТЬ, ЦЕНУ И СРОК ПОСТАВКИ, В СВЯЗИ С ОГРАНИЧЕНИЕМ ЭКСПОРТА ТОВАРОВ ИЗ СТРАН ЕС И ВЕЛИКОБРИТАНИИ

PCB Mount (Socket)

Complete with turned socket contacts these connectors will mount directly on to a PCB. Contacts are spaced at 0.2in. pitch. They will latch with cable shells, type A

QM Range Plastic Rectangular

Connector shells in nylon, with type A and type B locking together and are shaped to ensure correct orientation before engagement. Type A is cable mounting. Type B, whilst basically snap-in chassis mounting, may also be cable mounted if an in-line connection is required. Both will accept pin or socket inserts, which fit easily into the shells without the use of special tools. The inserts may be soldered or crimped and are available in three wire entry sizes.,Use hole cutter stock no. 543-709 for 24 way. Contacts must be ordered separately - see Range 'Contacts and Tooling.' (for example Crimp Single Piece Contact 466-804 Solder Cup Contact 329-8660 Crimp Tool 531-403)

Техническая спецификация
pdfTrident Snap Together PCB Connectors Product Data
Кол-во контактов:
24
Количество рядов:
4
Концевая заделка:
Припой
Номинал тока:
13.0A
Ориентация корпуса:
Прямой
Покрытие контактов:
Олово
Тип монтажа:
Сквозное отверстие
Шаг:
5.08мм
