MCPC2450E, Sensata / Crydom Solid State Relay, 50 A Load, Panel Mount, 280 V rms Load, 32 V dc Control, Реле

MCPC - Phase Angle Controller

Phase angle controller/SSR in one package. Ideal for any soft start / stop application requiring load control at multiple power levels for example heating elements, lamp brightness or motor speed (e.g. of a fan). The custom MCS / PC SSR provides the same ramp function as the standard MCS series, but an additional phase control function was added to the relay. The customer can therefore specify the amount of power they want applied to the load, then gradually ramp to that setting. If the power level is adjusted during operation, the relay will then gradually ramp to that new setting.

Provides a portion of each AC sine wave to control the amount of power delivered to an electrical load, with the percentage of power delivered determined by the input value
Reduced wiring and components in the panel saves time, cost and space
0 - 100% control range
Output status LED (Load Open, No Voltage)
Separate Output Enable/Disable control
SCR output

Note

Heat sink not included. For load current de-rating and heat sink details see manufacturers datasheet

Proportional and Power

Note

Temperature can affect current rating; please consult the data sheet for potential derating.

MCPC Series Data Sheet

Declaration of Conformity 2014/35/EU

CE Declaration of Conformity (2014/35/EU, 2015/863/EU)
