ABL8BPK24A03, Schneider Electric Extended Battery Module Battery Module, 24V dc dc Input, 24V dc dc Output, 20A Output, Блок питания

ABL 8BBU battery control modules and ABL 8BPK battery

For applications sensitive to power interruptions, the battery control modules are used to supply voltage after the network has been cut off, allowing for a back-up of the current values or the protection of certain actuators supplied with 24 Vdc.
Retaining duration is 9 minutes for 40 A and 2 hours for 1 A (according to the combination of control module/battery unit and charge).
Each battery module consists of lead acid batteries (two in series) and automotive fuse protection.
Only these modules are compatible with the ABL 8BBU series battery control modules.

Schneider Electric Battery Module, Includes Automotive Fuse, Screw Terminals - Phaseo Series - ABL8BPK24A03

Maintaining your industrial power supply through outages is easy as pie with the help of this battery module from Schneider Electric. Its generous capacity of 3.2Ah helps it provide continuous power for long-term backups. This means it can easily bridge the gap through blackouts lasting longer than a few seconds. The product's industry-standard 24V DC-rated voltage also makes it a smart choice when it comes to integrating with your industrial control networks. As it's designed to suit UPS units in Schneider Electric's Modicon series, finding a component to link it with is a breeze.

Features & Benefits

• LED diagnostics for effective troubleshooting power and operating status
• Fitted with a 20A automotive fuse to protect against overload and short-circuit faults
• Screw terminals for reliable electrical connections
• Adaptable unit suits any wire size between 0.5 and 10mm² (20 and 8 AWG) for versatility

Applications

• Production lines
• Robotics systems
• Industrial testing and measurement devices

How do I mount this device?

This module's a piece of cake to mount without any tools, thanks to its quick and simple snap-on DIN rail mounting mechanism. All you need is a standard 35mm rail.
