RS PRO 9 Way Right Angle Cable Mount D-sub Connector Plug, 2.77mm Pitch, Разъем

RS PRO 9-Way Right-Angle Cable Mount D-Sub Connector Plug, 2.77 mm Pitch

Need a connector plug to insert a D-sub cable into an electronic device? Choose this nine-way plug from RS PRO. It has a zinc-plated steel housing that's highly durable and protects the plug from corrosion and rust.


The plug has contacts made of brass for high conductivity, ensuring that it transmits current or signal efficiently and quickly. This material is also resistant to heat, so it prevents the contacts from overheating. A gold-over-nickel plating offers additional resistance to moisture and contaminants, protecting the plug against damage.


As part of the RS PRO range, this product has been tested for consistency and quality. A right-angle D-sub plug like this one is frequently used to create a connection on the back or side of a computing or electronic device.

Features and Benefits

• Right angle body orientation


• Brass contact material


• Gold-over-nickel contact plating


• Current rating of 3 A


• Dimensions of 30.81 (length) x 17.58 (width) x 12.55 mm (depth)


• Male gender


• Zinc-plated steel housing material


• Cable mounting type


• Nine contacts


• Pitch of 2.77 mm


• IDC (Insulation-Displacement Contact) termination method


• Voltage rating of 250 V
