193-KB20, Allen Bradley 193-K Overload Relay 1NO + 1NC, 1.4 → 2 A F.L.C, 2 A Contact Rating, 6 W, 690 V ac, Bulletin, Реле

193-K Miniature Bi-metallic Overload Relay

Protects motor against overload and phase loss
Trip class 10
Auxiliary switch 1N/O and 1N/C
Stable, shock-resistant direct mounting on 100-K contactor
Built in trip contact 95//96 and signal contact 97//98
Auto/manual reset selectable on device
visible trip indication
Test/trip actuator
Stop actuator

Allen Bradley Overload Relay, 2A, 6W - 193-KB20

Use this overload relay from Rockwell Automation's Allen Bradley range to protect your motors from overload and phase loss. It's an electromechanical device that will trip in 10 seconds or less in response to six times its operating current, making it an effective way to prevent damage to your motor. The terminals are positioned to prevent human contact, so you can be sure this overload relay is safe to handle. You'll commonly find components of this type used in large-scale industrial applications.

• Compact dimensions of 50 (L) x 44.9 (W) x 78.7mm (D) for use in tight spaces• Silver-plated contacts for good conductivity and reliable signal transmission• Wide operating temperature range of -20°C to +60°C for use in harsh environments• Screw terminals for secure connection and ease of installation• Clip-on DIN rail mounting design saves you time and effort

Standards and Certifications

• RoHS (Restriction of Hazardous Substances)• IEC (International Electrotechnical Commission)• CSA (Canadian Standards Association)

How do I reset this relay?

The relay offers a choice between manual and automatic reset, so you can pick the option that best meets your needs.
