RS PRO 200VA 2 Output Chassis Mounting Transformer, 50V ac, Трансформатор

RS PRO 200 VA 2 Output Chassis Mounting Transformer, 50 V AC

The RS PRO 200 VA two output chassis mounting transformer is a flexible tool for converting voltage levels. The unit comes with two independent secondary windings that you can connect either in series or in parallel to give a wide range of output voltage and current options. Chassis mounting transformers are commonly used in electromagnetic, electronic and electrical control applications.
The fully shrouded bobbins and complete varnish impregnation make this model stable and durable. Its tag terminations are ready for soldering and the unit comes with multiple frame-fixing holes to make chassis mounting easy.
As part of the RS PRO range, this product has been tested by leading engineers and meets the BS3535 and EN 60 742 standards for electrical safety. You'll often find chassis mounting transformers in relays, pumps and heating elements.

Features and Benefits

• Two outputs
• Primary voltage rating of 230 V AC
• Secondary voltage rating of 50 V AC
• Power rating of 200 VA
• Length of 100 mm
• Width of 92 mm
• Depth of 82 mm
• Fixing hole diameter of 5.5 x 8.5 mm
• Weight of 2.8 kg
• Operating frequency of 50-60 Hz
• Complies with RoHS (Restriction of Hazardous Substances) standards

Standards

BS3535; EN 60 742

RS PRO Datasheet
