RS PRO 200 VA 2 Output Chassis Mounting Transformer, 24 V AC

This 200 VA two-output chassis mounting transformer from RS PRO offers a flexible and dependable way to convert voltage levels. To provide a wide range of current and output voltage options, each unit has two independent secondary windings that can be connected in series or in parallel.
This model is sturdy and reliable thanks to fully shrouded bobbins and full varnish impregnation. The tag terminations can be easily soldered, and the unit has multiple frame-fixing holes for chassis mounting.
As part of the RS PRO range, this product has been tested for quality and reliability. It meets the BS3535 and EN 60 742 standards for electrical safety. You can use this transformer for various applications including relays, heating elements and pumps.

Features and Benefits

• Two outputs


• Primary voltage rating of 230 V AC


• Secondary voltage rating of 24 V AC


• Power rating of 200 VA


• Dimensions of 100 (length) x 92 (width) x 82 mm (depth)


• Fixing hole diameter of 5.5 x 8.5 mm


• Weight of 2.8 kg


• Operating frequency of 50 to 60 Hz


• Complies with RoHS (Restriction of Hazardous Substances) standards
