AL8Q-P00, Idec Push Button Bezel for Use with AL8 Series

Sub-miniature Lampholders

8mm contact indicators for panel mounting.

LED illumination
Indicators are available in both square and round styles
Suitable LEDs and lenses are supplied separately

LED
A range of LEDs specifically for use with this sub-miniature indicator series. Current should be limited to 20mA by use of a suitable external resistor as detailed at the beginning of the Optoelectronics/Indicators section. VF @ IF 20mA=1.7V (red), 2.1V (green) and 2.2V (yellow).
Lenses
Two-part lenses comprising a diffuser and a coloured transparent front cover. Diffuser may be marked to indicate switch function, etc.
Plug-In Base
A plug-in base which enables a switch or indicator to be surface mounted on a front panel or PCB.
Fitting Tool Kit
A fitting tool kit consisting of mounting tool, aligning tool, lamp remover and screen remover.

Datasheet - A Series Miniature Control Units
