LA4KE1B, Schneider Electric Tesys Surge Suppressor for use with CA Series, LC Series, LP Series

Plug-In, Coil Suppressors

Suppresses transient voltages in coils
Mounts directly onto contactor and control relay fronts even if auxiliary contact block is fitted
Incorporates an LED which will light up when the coil is energised

Schneider Electric Surge Suppressor, Clip-On Mounting, LED Signalling - LA4K Series - LA4KE1B

Keep hazards from voltage spikes at bay with this surge suppressor from Schneider Electric. As a varistor type, it diverts the excess voltage caused by lightning strikes or power fluctuations away from your equipment and into the ground. This protects you from electric shocks and helps to prevent fire outbreaks. A versatile safety device, it's compatible with many contactors, including those in the LC (188-4691), LP (758-787) and CA (824-2697) series. It's simple to monitor this surge suppressor thanks to its LED indicator, which lights up when the coil is energised, so you know it's doing its job.

Features & Benefits

• Compact dimensions of 25 (H) x 6 (W) x 22mm (H) make it a space-efficient choice for small setups
• Clip-on mounting is simple and doesn't need any tools, saving you time and hassle
• Light weight of 10g puts minimal pressure on your equipment
• Mercury-free construction for peace of mind and environmental safety

Applications

• Transportation industry
• Process and packaging plants
• HVAC systems

What ambient temperatures can this surge suppressor withstand safely?

This unit operates optimally in temperatures ranging between -25°C and +50°C, making it fit for use in demanding conditions.

K Mini Control Relays References

UL E164353

Datasheet

Product Environmental Profile
