8444 060500, Belden Multicore Industrial Cable, 0.36 mm², 4 Cores, 22 AWG, Unscreened, 152m, Chrome Sheath, Кабель

Belden Multicore Industrial Cable, PVC Outer Jacket, 4.7mm OD - 8444 060500

Need a reliable solution for transmitting multiple signals to your machinery? Send the right messages with this multicore industrial cable from Belden. There are four cores, each made up of seven strands, which are colour-coded to make connection to the right circuit easy. Thanks to its broad operating temperature range between -20°C and +80°C, this is a tough choice for use in harsh environments. Its tough PVC outer jacket has self-extinguishing properties to help stop flames from spreading if a fire breaks out.

• Jacket has nominal wall thickness of 0.81mm to resist tears
• Robust tinned copper conductors deliver high electrical conductivity
• Suitable for indoor use for safe operation

Applications

• Automotive engineering
• Audio-visual devices
• Oil and gas industry
• Telecommunications networks

How long is this cable?

As this cable is 152m long, you'll have enough at hand to reach devices that are set far apart or to cut down for multiple jobs.

Standards

NEC CMG; UL AWM 2576; CEC CMG

Datasheet

Cable Selection Guide
