RS PRO Force Gauge RS232, USB, Range: 980N, With RS Calibration, Датчик силы

RS Pro Digital Force Gauges

RS Pro Digital Force Gauges are handheld devices that allow measurement for quality control operating force. The software and electronics of the force gauge convert the voltage of the load cell into a force value that is displayed on the instrument. A use of a test stand enables high levels of repeat applications in standard test procedures.

Features and Benefits

Tension & compression capability
RS232 interface
SD card logging capability
Auto Zero, average & peak reading

Options

Force Gauge 5000 g, RS stock no: 111-3689
Force Gauge 20 kg, RS stock no: 111-3690
Force Gauge 100 kg, RS stock no: 111-3691

Application Information

Spring testing
Wire testing
Food quality
Weld force between electrodes

Supplied with

Carry case

RS PRO Force Gauge RS232, USB, Range: 980 N

If you need to measure the physical force of wire springs or the weld force between electrodes, this force gauge from RS PRO will convert the voltage of a load into a force value.

The instrument is capable of displaying force value kilograms, imperial pounds, or Newtons, has a range of 0 to 980 N (100 kg) and ±0.5% accuracy. The gauge uses a standard RS232 interface, which means it communicates with most computers, so you can download results directly to applications like Microsoft Excel. The device also accepts an SD card.

The force gauge is compact and portable, measuring 215 mm x 90 mm x 45 mm and comes with a durable carrying case. You'll frequently find force gauges used in workshops and manufacturing to measure compression and tension on different materials.

Features and Benefits

• Force gauge
• Range of 980 N (100 kg)
• Dimensions of 215 mm (L) x 90 mm (W) x 45 mm (D)
• 1.5 V battery type
• Operating temperature range of 0°C to +50°C
• Digital output of RS232, USB
• Measurement units in kg, lb and N
• Best accuracy of +0.5%
