21620003, Rose Aluminium Grey Camlock, Key to unlock, Замок

Rose Enclosure Accessories

Triangular Camlock for IP65 ABS Cabinet Enclosures.

Rose Camlock is a triangular shaped, 8 mm lock, suitable for IP 65, hinged, ABS mini control cabinet enclosures. The enclosures have a hinged lid designed for C & I equipment. The locks are easy to attach to the enclosure and add to the security of the equipment enclosed. There are 2 types of ABS enclosure suitable for this lock, one with an opaque door / lid and the other with a window supplying you with a transparent door / lid.

Camlock Features and Benefits.

•Triangular lock (3 sided).
•Size is 8 mm.
•Supplied as 1 piece.
•Made from aluminium.
•Also known as a Turn Bolt Fastener.
•Suitable for IP65 ABS Cabinet Enclosures.

Enclosure Features and Benefits.

•Made from ABS.
•Standard colour is light grey (RAL 7035).
•IP 65 to EN 60529.
•Impact resistant to 7 joule to EN 60079-0.
•Disruptive strength to IEC 60243-1.
•Fully insulated VDE 0100.
•Flame resistance to UL 94 HB.
•Surface resistance to IEC 60093.
•Halogen free.
•Enclosure opening angle is 135°.
•Enclosure temperature range -40°C to +60°C.

Suitable IP65 Enclosures.

•Stock number 1198401, part number 21.20 25 90, type ABS-K 1, 200 x 250 x 150 mm.
•Stock number 1198417, part number 21.25 30 90, type ABS-K 2, 250 x 300 x 170 mm.
•Stock number 1198401, part number 22.20 25 90, type ABS-KT 1, 200 x 250 x 150 mm.

Additional Accessories you may require.

•Stock number 1198495, Front plate.
•Stock number 1198530, External mounting brackets, 4 pieces.
•Stock number 2549232, Socket wrench, square drive 8 mm.

Enclosures featured come with 22mm holes unless otherwise stated.

GFK Fiberglass/ABS Mini Cabinets Data Sheet
