GRLA-1/8-QS-6-RS-D, Festo GRLA Series Tube Exhaust Valve, 6mm Tube Inlet Port x G 1/8 Outlet Port, 197581

Festo Exhaust Valve, 3Nm Tightening Torque, 185L/min Nominal Flow Rate - GRLA-1/8-QS-6-RS-D

When compressed air is flowing through your pneumatic system, you need a way to reliably control it. That's where this exhaust valve from Festo comes in. Its one-way function means it regulates a pneumatic driver's piston speed by adjusting airflow. The robust unit stands up to corrosion and chemicals thanks to its sturdy aluminium metal body and nitrile rubber seal. Combining a G1/8 threaded outlet port and a 6mm tube inlet port, it's widely compatible and compact enough to fit where space is limited. As the inlet has an integrated QS push-in fitting, installation and mounting are a breeze.

Features & Benefits

• Handles demanding operating temperatures between -10°C and +60°C
• Performs reliably in a wide operating pressure range between 0.2 and 10 bar
• Withstands a 185L/min standard nominal flow rate for use with challenging applications
• Weighs just 23g, so it won't overload your pneumatic system
• Swivel-type fitting means you can install in multiple directions to best fit your setup

Applications

• Food and beverage production
• Automated assembly lines
• Automotive manufacturing

How do I adjust this exhaust valve?

When you need to control airflow, it's easy to tweak the valve's settings by manually adjusting the knurled screw with a slotted screwdriver.
