GRLA-3/8-QS-10-D, Festo GRLA Series Tube Exhaust Valve, 10mm Tube Inlet Port x G 3/8 Outlet Port, 193151

Festo Exhaust Valve, G3/8 Threaded Outlet Port, 60g Weight - GRLA-3/8-QS-10-D

To safely control pneumatic driver speeds, add this exhaust valve from Festo to your setup. It maintains a steady flow rate to regulate piston movement during advance and return strokes. The valve has a one-way flow control system that's quick to set accurately with a standard slotted screwdriver. As it has a G3/8 threaded outlet port, it's widely compatible with connecting parts. The inlet has a push-in fitting for quick and easy mounting. This is a sturdy and corrosion-resistant option thanks to a wrought aluminium alloy body with a brass adjusting screw.

Features & Benefits

• Safely handles a nominal flow rate up to 900L/min for use with fast-paced applications
• Performs reliably in a broad operating temperature range between -10°C and +60°C
• 10Nm nominal tightening torque makes it robust enough to support heavy loads

Applications

• Medical facilities
• Textile processing
• Industrial manufacturing

What size is the valve's inlet port?

The valve has a tube inlet port that's just 10mm in size, making it a compact choice for smaller systems.

What operating medium does this unit handle?

This versatile exhaust valve is compatible with pneumatic systems using compressed air.
