GRLZ-M5-QS-6-D, Festo GRLZ Series Tube Flow Regulator, 6mm Tube Inlet Port x M5 Male Outlet Port, 193155

Festo Flow Regulator, 6mm Tube Inlet Port - GRLZ Series - GRLZ-M5-QS-6-D

This flow regulator from Festo is ideal for controlling the flow rate of fluids in pneumatic systems. Its one-direction, no-return function allows you to regulate the flow rate for the advance or return stroke of a cylinder. You can easily adjust the flow using the slotted-head screw.
The unit is suitable for use with compressed air and can operate at temperatures ranging from -10˚C to +60˚C, making it suitable for use in a wide range of common industrial environments. One connector is a metric standard 5 mm male thread, while the other is a 6 mm push-in type for easy installation and uncoupling. Nitrile rubber (NBR) seals make the connections secure.

• Durable brass body material resists corrosion
• Can be swivelled 360˚ around the screw-in axis after mounting
• Weight of 13 g reduces gravitational stress on systems
• A standard flow rate of 170 L/min and standard nominal flow rate in flow control direction of 115 L/min means it can handle large volumes
• Pressure control lets you select slow, fast or medium piston movement

Festo GRX-VFO

GRLZ-M5-QS-6-D Specification Sheet
