DSBC-32-200-PPVA-N3, Festo Pneumatic Piston Rod Cylinder - 1376429, 32mm Bore, 200mm Stroke, DSBC Series, Double Acting, Пневмоцилиндр

Festo Pneumatic Piston Rod Cylinder, 0.6 to 12 Bar Operating Pressure Range, M10 Piston Rod Thread - DSBC-32-200-PPVA-N3

Need to get your automated application moving in the right direction? This Festo pneumatic piston rod cylinder delivers strokes up to 200mm long, quickly shifting goods across your setup for speedy sorting. As a double-action unit, it uses air to extend and retract its piston, to achieve accurate two-way movement every time. Because it's compatible with both clean and lubricated compressed air, this is a sure fit for standard pneumatic systems. The cylinder slots into place with a simple M10-thread port, meaning it's a cinch to install.

Features & Benefits

• Adjustable cushioning at both ends to prevent impact damage
• Die-cast aluminium casing resists corrosion, ensuring a long service life
• Measures just 45 (W) x 45 (H) x 345.1mm (D) for easy mounting in busy setups
• Sealed with PU O-rings to cut the risk of pressure loss through leaks

Applications

• Automotive industry
• Processing plants
• Small parts manufacturing

Can I use this cylinder in extreme temperatures?

Yes. This pneumatic cylinder works in operating temperatures between -20°C and +80°C, giving you reliable performance in demanding industrial settings.

Festo DSBC

Festo Pneumatic Cylinders Operating Manual

DSBC-32-200-PPVA-N3 Specification Sheet
