VSNC-FC-M52-MD-G14-F8, Festo 5/2 Pneumatic Solenoid Valve - Solenoid/Spring G 1/4 VSNC Series 24V dc, 577257, Клапан

Festo Pneumatic Solenoid Valve, 2.5 to 10 Bar Operating Pressure Range, Convertible 5/2-Way or 3/2-Way Type - VSNC-FC-M52-MD-G14-F8

Get your industrial process flowing with this pneumatic solenoid valve from Festo. When supplied with 24V DC, the nifty device uses a built-in poppet mechanism to let you stop or change the direction of the airflow. The wrought-aluminium-alloy housing is corrosion-resistant, making this an ideal choice for humid work areas. Hot conditions are no trouble for this hardy piece of kit thanks to its broad operating temperature range between -20°C and +60°C.

• Standard nominal flow rate of 1,250L/min shows it's suitable for heavy-duty applications
• IP65 rating indicates it's dust-tight and withstands low-pressure water jets from any direction
• NBR seals are resistant to oil damage to ensure a leak-free service life in harsh work areas
• Light weight of 380g to minimise pressure on your mounting surface

Applications

• Large industrial valves
• Tool actuation
• Process automation and control

What type of port configuration does this unit use?

Three of this unit's pneumatic connections have a G1/4 thread, while the other two are configured according to the NAMUR pattern standard, for wide compatibility with standard connecting parts.

Festo VSNC

VSNC-FC-M52-MD-G14-F8 Specification Sheet

Brochure - Simply Part Of The Solution

Instruction Sheet - VSNC-F
