VUVG-LK10-B52-T-M5-1H2L-S, Festo 5/2 Solenoid Valve - Solenoid/Solenoid Metric M5 VUVG Series 24V dc, 8042540, Клапан

Festo Solenoid Valve, 0.7W Solenoid Power Consumption, Aluminium Alloy Body - VUVG-LK10-B52-T-M5-1H2L-S

If you're looking for a high-performance in a compact package, try this solenoid valve from Festo. Despite its 10mm valve size, this mini marvel can control the flow of compressed air in your pneumatic system up to a maximum flow rate of 195L/min. As the solenoid uses just 0.7W during operation, it's also an energy-efficient option. The 5/2 port and position configuration makes this unit a smart choice for controlling double-acting actuators.

Features & Benefits

• M5 connection port thread for wide compatibility
• Aluminium alloy body is tough and corrosion-resistant
• Wide operating pressure range between 1.5 and 7 bar for versatile use
• Inline mounting style saves space in a busy setup
• Works effectively in a wide operating temperature range from -5°C to +50°C

Applications

• Textile industry
• Logistics centres
• Mechanical workshops

Does this valve have an IP rating?

Yes. It has an IP40 rating, which means that it's protected against solid objects larger than 1mm. It's also touch-proof, so you can handle it safely without risking an electric shock.

How can I check the status of the valve?

It has an LED, so you can confirm the unit's signal status at a glance.
