VUVG-LK10-M52-AT-M7-1R8L-S, Festo 5/2 Solenoid Valve - Solenoid/Spring M7 VUVG Series 24V dc, 8042551, Клапан

Festo Solenoid Valve, Compressed Air Medium, Electric Actuation Type - VUVG-LK10-M52-AT-M7-1R8L-S

Do you need a fuss-free way to control fluid flow in your system? This 5/2-way monostable solenoid valve from Festo does the job. When linked to a 24V DC energy source, the unit's coil is activated by an electrical signal to adjust the built-in plunger, causing the airflow to stop or change direction. Its NBR seals are abrasion-resistant to prevent leakage that could cause a pressure drop. Thanks to this valve's maximum operating temperature of +50°C, it beats the heat in harsh work conditions.

• LED signal display lets you monitor the status of your valve at a glance
• Mountable in any position to allow for flexible fitting
• Light weight of 45g limits the strain on your mounting surface
• IP65 rating shows it's dust-tight and withstands low-pressure water jets from any direction

Applications

• HVAC systems
• Compressed air tools
• Medical technology

What's this unit's operating pressure range?

This solenoid valve has a wide operating pressure range between 2.5 and 7 bar, so it's a versatile piece of kit.

Can I use this product in heavy-duty applications?

Yes, you can. This valve's high standard nominal flow rate of 340L/min makes it an ideal choice for heavy-duty applications.

Festo VUVG

VUVG-Series Order Code Overview

VUVG-LK10-M52-AT-M7-1R8L-S Specification Sheet

Brochure - VG Series
