VUVS-LK20-M52-AD-G18-1C1-S, Festo 5/2 Solenoid Valve - Solenoid/Spring G 1/8 VUVS Series 24V dc, 8043214, Клапан

Festo Long-Lasting Pneumatic Solenoid Valve, G 1/8, 24V DC - VUVS Series - VUVS-LK20-M52-AD-G18-1C1-S

This sturdy solenoid valve from Festo employs a reliable piston-slide structure to regulate the flow of liquid or gas in pneumatic systems. Its internal air-spring reset ensures a quick open/close response when the solenoid actuator is triggered. The valve operates via a 5-way port that allows for maximum outflow. It comes with pre-assembled parts that are easy to set up and install. Thanks to a nominal flow rate of 500l/min, you'll find this durable solenoid valve ideal for use in medium-volume pneumatic vacuum equipment.

• Operating temperature range of -5°C to +50°C makes it suitable for extreme conditions
• Corrosive-resistant aluminium-alloy body prevents rust damage
• Easy-to-operate piston slide design
• Manual override operating option available for versatility
• Automatic electrical actuation for fast action

Application Information

• Vacuum systems
• Packaging applications
• Heating and cooling systems

How durable is this pneumatic solenoid valve?

This Festo valve is a long-lasting component.It has an IP (ingress protection) rating of IP67, meaning it's completely dust-tight and can be immersed in up to 1 metre of liquid for 30 minutes. It resists corrosion and rust, making it durable and suitable for harsh conditions.

Festo VUVS

VUVS-LK20-M52-AD-G18-1C1-S Specification Sheet

Brochure - Order guide for standalone valves
