VUVS-LK25-B52-D-G14-1B2-S, Festo 5/2 Solenoid Valve - Solenoid/Spring G 1/4 VUVS Series 24V dc, 8043219, Клапан

Festo Solenoid Valve, 12ms Changeover Time, 26.5mm Valve Size - VUVS-LK25-B52-D-G14-1B2-S

Get your pneumatic system up and running with this 5/2 solenoid valve from Festo. It directs airflow through five ports, making it ideal for double-acting devices like cylinders. The energy-efficient unit propels air tools and small motors while consuming just 3.3W of power. As it handles between 1.5 and 8 bar of pressure, it's ideal for light-duty and medium-duty applications. A throttleable exhaust gives you precise control over pressure in your system.

Features & Benefits

• IP65-rating indicates it's dustproof and water resistant, for reliable performance in demanding settings
• Wide operating temperature range between -5°C and +50°C for use in tough environments
• Standard G1/4 connecting ports allow for quick installation in your existing setup

Applications

• Automated manufacturing systems
• Food production facilities
• Packaging equipment

How does this solenoid valve work?

When energised, this component's electromagnetic coil generates a magnetic field that draws the piston up or down to direct airflow. When power is cut, a spring returns the piston to the starting position.

How do I mount this valve?

Mounting this device directly on a manifold rail and securing it in place is quick and easy, thanks to the through-hole design.

Datasheet

VUVS-LK25-B52-D-G14-1B2-S Specification Sheet
