QS-G1/8-6, Festo QS Series Straight Threaded Adaptor, G 1/8 Male to Push In 6 mm, Threaded-to-Tube Connection Style, 186096, Переходник

Festo Pneumatic Fitting, Straight Threaded-to-Tube Adaptor, G1/8 Male to Push-In 6mm - QS-G1/8-6

Make quick and easy connections in your pneumatic system with this threaded-to-tube adaptor from Festo. The body and thread are made of nickel-plated brass to combine strength with corrosion resistance. This material ensures a long service life and avoids contaminating your system with metals. Port 1 is a standard G1/8 male thread for compatibility with common system components. Port 2 has a 6mm outside diameter and a push-in connection, so you won't need any tools when installing the tube.

• Operating temperature range of -10°C to +80°C makes it suitable for use in harsh industrial environments
• Suitable for use with air pressures up to 14 bar for versatility
• Low weight of 8.3g for easy handling

Applications

• Assembly and production lines
• Workbench equipment
• Construction sector

What types of pneumatic fittings are available?

Pneumatic fittings are available in a number of standard forms, including straight, T-shaped and Y-shaped. There are also pneumatic function fittings, which can be used to perform functions including exhaust, flow regulation and silencing. Straight fittings are versatile as they can accommodate many types of commonly used hoses in the tube connection.

Festo Push-in fittings & Connectors QS

QS-G1/8-6 Specification Sheet
