691508110303, Wurth Elektronik 5081 Series PCB Terminal Block, 3-Contact, 3.5mm Pitch, Surface Mount, 1-Row, Solder Termination

Wurth WR-TBL 5081 Series 3.5mm SMT Terminal Block Connectors

WR-TBL 5081 series PCB SMT mount terminal blocks with a 3.5mm pitch and a wire entry horizontal to the PCB. These 5081 series 3.5mm terminal blocks have a pressure clamp system for a secure connection to the conductor using an M2 screw and tin plated brass clamp. The housings of these PCB terminal blocks are made from grey UL94-V0 LCP and feature alignment pegs to assist with positioning on the PCB during the soldering process. These 5081 series 3.5mm SMT terminal blocks will accept solid and stranded wire sizes of 30-16 AWG (0.05 to 2mm²)

Wurth 3.5mm Pitch Terminal Blocks

5081 series 3.5mm right angle SMT terminal block
