JCA1005D01, XP Power JCA DC-DC Converter, ±5V dc/ ±800mA Output, 4.5 → 9 V dc Input, 10W, Through Hole, +100°C Max Temp, Преобразователь

XP Power - JCA Series of 10 W Isolated DC-DC Converters

The JCA series from XP Power offers a highly reliable range of single and dual output, 10 W, isolated DC-DC converters. The series attributes 1500 VDC input to output with basic insulation, 500 VDC input to case and 500 VDC output to case. The range is available in a compact 1.0” x 0.8” metal package, has a 2:1 input range and has been fully UL and TUV approved.

10 W, isolated DC-DC converters
Compact metal 1.0” x 0.8” package
2:1 input range
1500 VDC input to output with basic insulation
500 VDC input to case, 500 VDC output to case
Single and dual output
High efficiency up to 85%
-40 °C to +100 °C Operating temperature
Board mount
Industry standard pin out
UL and TUV approved

XP Power - Isolated DC-DC Converters

Datasheet
