RS PRO 230V ac, 2 x 40V ac Toroidal Transformer, 1000VA 2 Output, Трансформатор

RS PRO 230 V AC, 2 x 40 V AC Toroidal Transformer, 1000 VA, 2 Output

This RS PRO toroidal transformer is ideal for stepping voltage up or down in control circuits. It has a primary voltage rating of 230 V AC and a secondary voltage rating of 2 x 40 V AC, so you have the option to charge two devices simultaneously.
The transformer's core delivers low loss and low noise for more reliable performance. It incorporates primary windings and twin secondary windings, which you can connect either in series or in parallel to build multiple circuit layouts. The centre hole fixing enables you to mount the transformer easily. Low energy dissipation makes this an efficient and environmentally friendly component.
It's Restriction of Hazardous Substances certified, which guarantees that it's free of harmful materials. This part is frequently used to power electrical appliances such as computers, home theatre installations and cordless power tools.

Features and benefits

• Double output
• Lead wire termination type
• Surface mounting
• Operating frequency of 50 to 60 Hz
• Diameter of 162 mm
• Height of 70 mm
• Weight of 6.5 kg
• Power rating of 1000 VA

RS Pro Toroidal Transformer Datasheet

RS PRO Suggested Mounting Discs for toroidal transformers (Accessory Overview)
