SV431DUSBU, Startech 4 Port USB VGA KVM Switch

SV431DUSBU VGA KVM Switch

The SV431DUSBU 4 Port 1U Rack Mountable USB KVM Switch with OSD lets you control multiple USB based computers from a single console (USB keyboard, USB mouse, monitor).

Convenient push-button and hot-key controls provide quick, reliable switching between connected computers while manual and auto-scan switching modes and an On Screen Display (OSD) offer additional control options.

Designed to ensure maximum space efficiency, the USB KVM switch features a slim 1U design that fits neatly into a server equipment rack/cabinet (with optional mounting bracket SV431RACK) and offers rear cable connections to eliminate cable tangles and minimize workspace disruption.

This product is TAA compliant and backed by a Startech.com 3-year warranty with free lifetime technical support.

Rackmount your KVM switch

If you’d like to mount this KVM switch to your server rack, StarTech.com offers a 1U Rackmount Bracket (sold separately) that turns this KVM into a rackmountable KVM.

The SV431DUSBU only works with specific 2-in-1 VGA and USB cables (sold separately), a list of StarTech.com approved cables are below:

6 ft Ultra Thin USB VGA 2-in-1 KVM Cable
6 ft Ultra Thin USB VGA 2-in-1 KVM Cable
10 ft Ultra Thin USB VGA 2-in-1 KVM Cable
15 ft Ultra Thin USB VGA 2-in-1 KVM Cable

Features & Benefits

• OS Independent – No drivers or software required
• Auto-scan function automatically selects computer sequentially
• Front panel push-button and Hotkey switching allow easy computer access
• Identifies and selects computers by the names assigned using the OSD
• USB console connections
• Rename connected computers for easy identification
• OSD security allows each PC to be password protected
• Plug-and-play system configuration
• Rugged, all-metal 1U chassis for use in harsh environments and space-saving cabinets
• Supported Wide Screen Resolutions: 1920x1200, 1920x1080, 1680x1050, 1400x1050, 1440x900, 1360x768
• Supported 4 : 3 Resolutions: 1920x1440, 1600x1200, 1280x1024, 1024x768
• Extracting the keyboard strokes from the USB connection this KVM enables hot key support for wireless keyboard and mouse combo kits that use a single USB receiver
• On Screen Display adds the ability to rename connected computers for easy identification and provides per-port password security
• Absolutely no software or drivers required providing a completely OS independent KVM solution

What’s in the package?

• 4-port KVM switch
• foot pads
• universal power adapter (NA/EU/UK/AU)
• instruction manual

FAQs

Can I use any mouse or keyboard with the KVM Switch?
It will depend on the type of mouse or keyboard used. It is advised by the manufacturers to use standard wired 104 key keyboards and a standard wired mouse that does not have additional features. This includes wireless, gaming and Apple keyboards.

SV431DUSBU Datasheet
