RS PRO Panel Mount PID Temperature Controller, 48 x 48mm, 2 Output Relay, 110 → 240 V ac Supply Voltage, Регулятор температуры

RS PRO Panel Mount PID Temperature Controller, 48 x 48 mm, 2 Output Relay, 110-240 V AC Supply Voltage

If a traditional temperature controller isn't precise enough for your needs, you could always consider a PID controller instead. Proportional integral derivative controllers such as this one from RS PRO use a very precise control loop mechanism to ensure process temperatures remain stable when it counts.

While standard controllers can only switch between on and off – leading to overshoots and lag in process temperatures – PID controllers rely on feedback from a thermocouple to make more accurate readings. This means they're much better at responding to sudden fluctuations in temperature, making them ideal for manufacturing applications where this kind of quick response is crucial.

The PID temperature controller is extremely user-friendly, with a large, readable LED display, quick set-up menu and simple three-button operation. The controller comes with an easily installed panel mount. Part of the quality RS PRO range, this product has been stringently tested for safety.

Features and Benefits

• PID temperature controller
• Analogue input for thermocouple Type B, Type C, Type J, Type K, Type L, Type N, Type R, Type S, Type T and PT100
• Relay output type
• Supply voltage of 110-240 V AC
• Measures 48 x 48 mm
• Panel depth of 67 mm
• Panel mounting
• Two outputs
• Temperature range of -200°C to +2320°C, depending on thermocouple type
• Minimum operating temperature of 0°C
• Maximum operating temperature of +55°C
• Dual 4-digit LED display
• Setup menu with 10 configuration parameters
• Suitable for applications where primary temperature controls (e.g. heat/cool) are needed
• IP20- and IP65-rated as dust-tight and splash-proof
• Complies with EN 61326 (Susceptibility & Emissions)
• Complies with EN 61010-1 (Safety requirements for electrical equipment for measurement, control and laboratory use)
