RS Pro Digital Process Indicator- Linear Input

RS Pro process indicator has linear mA and V input, rescaled for accurate display of process data. The indicator has selectable input types and has an easy to adjust sampling time. It has multiple display options and can be easily set up to meet your specific needs.

Features and Benefits

• Indicator only, no outputs
• 35 x 77 mm size
• LCD digital display, 4-digits
• DC linear input (0-20 mA, 4-20 mA, 0-1 V, 0-10 V)
• Adjustable display scale between -1999 and 4000
• Decimal point adjustment –zero to three decimal places
• Process unit can be displayed
• User calibration
• Selectable sampling time
• Max. and Min. measured values stored
• Max. or Min. display modes
• High and low alarm limits
• CE certified
