DAT71210U/RS, Sensata / Cynergy3 PCB Mount Reed Relay, 12V dc Coil, SPST, 7000V Max, 2 A Max, 150Ω, Реле

Sensata Cynergy3 SPNO Reed Relay, 3A Maximum Switching Current, 50W Switching Power - DA (UL) Series - DAT71210U/RS

Use this reed relay from Sensata Cynergy3 to control circuits on printed circuit boards (PCBs). It works by using an electromagnetic coil to make or break the connection of its contacts. This component's normally open configuration means there's no current flow in its default state until it's energised. Its tungsten contacts are resistant to heat and impact, making it a good choice for use in demanding applications. You'll commonly find this reed relay used in high-voltage applications in the medical and instrumentation industries.

Features & Benefits

• Compact dimensions of 60 (length) x 15.8 (depth) x 18.5mm (height) for installation in areas where space is limited
• Broad operating temperature range of -20°C to +70°C for use in hot and cold environments
• Long electrical service life of 1,000,000,000 dry switching operations for long-lasting performance
• Fast operating time of 3ms for a rapid response

How do I mount this reed relay?

This reed relay is designed to be mounted directly onto the PCB. It has pin terminals for ease of installation.
