DAT72410U/RS, Sensata / Cynergy3 PCB Mount Reed Relay, 24V dc Coil, SPST, 7000V Max, 2 A Max, 780Ω, Реле

Cynergy 3 DA (UL) Series Reed Relay

The UL approved reed relays have very high isolation voltages. UL reed relays are ideal for applications that require high reliability, these include cardiac defibrillators, test equipment and high voltage power supplies.

Features and Benefits

10kV isolation
Low contact resistance
Panel mount or PCB
HV connections through Flying Leads, Solder Turret (wire wrap) or 1/4inch Spade Terminals
AC characteristics

Note

The rhodium contact relays have low contact resistance, the tungsten contact relays can switch to higher voltages.

Approvals

UL

Sensata Cynergy3 Reed Relay, SPNO Configuration, 24V DC Coil Voltage - DA (UL) Series - DAT72410U/RS

This reed relay from Sensata Cynergy3 provides a fast and dependable way to control circuits on your PCB. It works by using an electromagnet to open or close a circuit. The contacts are made from tungsten for resistance to heat and corrosion, ensuring reliable switching. It has a maximum switching voltage of 7000V AC/DC for use in high-power applications. You'll find this reed relay used in applications such as high-voltage power supplies and test equipment.

Features & Benefits

• Broad operating temperature range between -20°C and +70°C for use in harsh environments
• Robust service life of up to one billion dry switching operations for long-term performance
• Rapid response time of 3ms for fast switching

How do I mount this reed relay?

Thanks to its 4-pin terminals, you can easily mount this reed relay directly onto your PCB panel.

What are the dimensions of this reed relay?

This reed relay has compact dimensions of 60 (length) x 15.8 (width) x 18.5mm (height), so it won't add too much bulk to your setup.

Cynergy3 DA (UL) Series Reed Relay

DA (UL) N/O, HIGH VOLTAGE RELAYS - 10KV, 7.5KV & 5KV Series Datasheet
