RS PRO Circular Connector, 2 Contacts, Cable Mount, Plug, Male, IP68, Разъем

Cable Plug 25A Circular Connectors (Threaded) IP68

From RS Pro, a range of threaded circular connectors designed for industrial applications. The IP68 fully sealed cable mount plugs provide a secure, watertight connection. With a knurled locking ring the versatile cable mount plugs are easily mated with cable sockets for in-line cable to cable connections. Alternatively, the cable mount plugs can be mated with panel mount sockets for cable to panel connections. The RS Pro range of sealed circular connectors features screw terminals, and require no additional specialist tooling. This makes them ideal for field applications or areas that require regular maintenance.

Features & Benefits

• IP68 ingress protection rating
• -25 to + 85°C temperature range
• Robust Nylon 66 outer shell
• High-performance PPS insert
• Gold plated brass contacts
• Screw termination, ideal for field applications
• Easy to assemble – no special tooling required
• V-0 fire rating
• 7 mm to 12 mm o/d cable acceptance
• 2, 3 and 5 pole variants

Applications

The RS Pro threaded circular connectors are ideally suited to industrial applications. Due to their excellent environmental resistance properties, these threaded circular connectors are perfect for harsh environments that require a higher level of protection. So of the most common areas are;

• Tooling & Machinery
• Industrial Process Control
• Industrial Robotics
• Industrial Automation

Environment

These RS Pro waterproof cable mount connectors are fully sealed and have an IP68 ingress protection rating. This means that when mated with the appropriate cable or panel sockets the connectors are dust tight and are protected against powerful jets of water from all directions and partial submersion.

FAQ

Q - Are the connectors easy to terminate?
A – Yes, this range of connectors have screw terminals so no special tooling is required.
Q – How durable are the connectors?
A – The RS Pro threaded circular connectors are manufactured from high-grade engineering materials. They are robust, strong and reliable.

Mating Parts

• 124-6686 is a 2 pole cable mount plug and mates with 124-6664 in-line socket or 124-6671 panel socket
• 124-6687 is a 3 pole cable mount plug and mates with 124-6665 in-line socket or 124-6672 panel socket
• 124-6688 is a 5 pole cable mount plug and mates with 124-6666 in-line socket or 124-6673 panel socket

RS PRO Connector, 2 contacts Cable Mount Plug, Screw IP68

RS PRO screw-termination circular connectors offer an efficient and reliable method to establish wire connections without the need for special tools. This male plug connector can be used for both cable-to-cable and cable-to-panel connections and is threaded for easy on-site assembly and disassembly.

The connector is designed for a wire diameter range of 7mm to 12mm. Encased in a nylon 66 shell, the 2-contact plug can endure significant temperature variations in the range of -25°C to 85°C. An IP68 rating means this connector can weather dusty, dirty and sandy conditions. As part of the RS PRO range, the product is strictly tested for quality and compliance before it gets the RS seal of approval.

As they are durable in tough conditions, screw-termination circular connectors are popular in tooling, automation, robotics and process control applications.

Features and Benefits

• 2-contact male plug connector
• Gold-plated brass contacts offer enhanced rust and corrosion resistance
• Screw termination, ideal for field applications
• Supports 7 mm to 12 mm cable diameter
• Polymer housing
• Operating temperature range from -25.0°C to 85°C
• Current rating of 25 A
• Voltage rating of 500 V
• Brass contact material
• Gold contact plating
• Adherers to ANSI/ESD S20.20:2014 and BS EN 61340-5-1:2007 compliance standards (handled and packaged in controlled environments that prevent damage due to electrostatic discharge)

RS PRO

RS PRO is our own brand range and brings you a wide range of high-quality, great value products offering you more choice. Trusted by engineers all over the world, every part of every RS PRO product has been rigorously tested against demanding industry standards
they’re only given the RS PRO Seal of Approval if we’re confident of their exceptional quality, which means you can be confident too.

Note

This product could be provided in either blue/black or and all black variant
