Siretta QUARTZ-W22-LTE(EU) + ACCESSORIES 3G, 4G, 1 x RS-232, 2 x LAN, 2 x SIM, 3 x I/O Ports

Siretta QUARTZ 4G WiFi Dual Sim Dual LAN Router With Accessories

The QUARTZ-LTE router, has an array of features to empower your application. These include a dual SIM facility meaning you can configure a back-up cellular network between two different SIM cards, to ensure permanent reliable connection regardless of individual network availability. In addition, the QUARTZ-LTE has dual port ethernet capability, RJ45 serial RS232 port and 3 digital I/O and comes as standard with LTE/4G antennas, but it has the option to come with, or without, Wifi. It also has optional GPS capability, which means the router is ideal for asset tracking or access management.

Features & Benefits

European 4G LTE bands
Dual SIM
Dual LAN
2.4 GHz Wi-Fi support
RS232 Via linkCONNECT RJ45
High speed data via LTE network
Strong resistance to electromagnetic interference
Built-in watch dog
multi-link detection
Compact industrial design
Excellent temperature endurance
VPN: PPTP, L2TP, GRE, IPSec

Physical Interfaces

2 x 10/100 RJ-45 Ethernet Interfaces
1 x RS232 linkCONNECT RJ45 Interface
3 x I/O (Input/Output – user defined)
2 ´ Standard SIM/R-UIM interface
1 x RP-SMA (Male) Wi-Fi Interface
2 ´ SMA (Female) Cellular interface
1 ´ DC Power Interface (7.5 to 32 V DC)

Applications

Payment Services
Vending machine connectivity
Retail POS
Internet based Video surveillance
Digital signage

Accessories Included

1 x Cellular Antenna
1 x Wi-Fi Antenna
1 x LAN Cable
1 x Power Block Interface
1 x Multi Head Power Adaptor
1 x DIN Rail Adaptor

Certifications

CE
UKCA
RoHS

QUARTZ LTE EU Datasheet

QUARTZ Series Hardware Manual

QUARTZ Series Software User Manual
