RTH-B224 Module Type, Rohde & Schwarz Oscilloscope Module 500 MHz Bandwidth Upgrade RTH-B224, For Use With RTH1002 Series

Rohde \u0026 Schwarz RTH1002 Scope Rider Handheld Digital Oscilloscope 60 MHz 2 Channels DMM
Rohde \u0026 Schwarz Scope Rider RTH1002 offers the performance and capabilities of a laboratory oscilloscope together with the form factor and ruggedness of a battery-operated handheld device. Digital control signals can be analysed with the 8-bit logic interface that is isolated from the analog input channels. The protocol trigger and decode capabity is unprecedented in handheld oscilloscopes and provides direct display of decoded messages. If extra safety is required, the RTH1002 can be remotely controlled with the Web browser via wireless LAN, separating the measurement location from the place where the user controls the instrument.
Features and Benefits
60 MHz with 5 Gsample/s sampling rate2 isolated channels with CAT IV 600 V / CAT III 1000 V rating10-bit ADC50000 waveforms per secondCapacitive touch and keypad operation5 integrated modes: lab performance oscilloscope; logic analyser; protocol analyser; data logger; digital multimeter (integral)IP51 housing meeting military environmental requirementsWireless LAN and Ethernet for web-based remote control and quick data accessBattery operates for more than 4 hours on one charge
Areas of Application
Safe debugging of embedded power suppliesFast debugging using specialised triggersWireless control can be used for increased operator safetyQuick and efficient troubleshooting
Bandwidth Upgrades
To preserve your oscilloscope investment as your requirements change, four bandwidth upgrades are avalable: 100MHz 200Mhz 350Mhz and 500Mhz (RS Stock No's. a href=\"/web/p/products/1259465\""125-9465/a, a href=\""/web/p/products/1259466\""125-9466/a, a href=\""/web/p/products/1259467\""125-9467/a, a href=\""/web/p/products/1259468\""125-9468/a respectively).
500 MHz, 10:1, 600 V CAT IV voltage probe (1 per channel), 600 V CAT IV test lead (1 per meter input), user manual, lithium-ion battery pack, power supply with plugs for EU, CH, UK, US, CAN, China, Australia
Rohde \u0026 Schwarz Scope Rider Handheld Digital Oscilloscope System
