2060-452/998-404, Wago 2060 Series PCB Terminal Block, 2-Pole, Female, 2-Way, PCB Mount, 9A

Wago PCB Terminal Block, Push-In Terminals, 4mm Pin Spacing - 2060 Series - 2060-452/998-404

Keep your wiring safe as houses using this PCB terminal block from Wago. It's designed for both manual and automated wiring systems, so it's a great shout for many different applications. This socket accepts solid and stranded conductors ranging in size from 24 to 18AWG, making it a versatile piece of kit. Push-in terminals make hooking up solid wires a cinch without the need to reach for tools. For all other conductor types, the connector's handy push buttons mean insertion and removal is a piece of cake.

Features & Benefits

• Rated impulse voltage of 2.5kV for protection against power spikes
• Compact dimensions of 4.5 (H) x 7.9 (W) x 13.1mm (D) to maximise space on your board
• Copper alloy contacts are highly conductive and resistant to corrosion for a reliable connection
• Stops burning in 10 seconds or less for safety in the event of a fire

Applications

• Medical centres
• Industrial automation
• Laboratories and testing facilities
• Textile manufacturing

Can I solder this terminal block directly onto a PCB?

Yes, this connector is delivered in tape and reel packaging, so you can conveniently solder it straight to your board using automated placing equipment.

Wago PCB Terminal Blocks

Datasheet
