XCSDMP501L01M12, Telemecanique - Preventa XCSDMP Magnetic Safety Non Contact Switch, Plastic, 24 V dc, 1NC/2NO, Выключатель

1330079
Номер производителя: XCSDMP501L01M12Производитель: Telemecanique
Цена за шт.
28419.00 руб. (С НДС) *

Срок поставки: 4-6 недель

+

* УТОЧНЯЙТЕ ВОЗМОЖНОСТЬ, ЦЕНУ И СРОК ПОСТАВКИ, В СВЯЗИ С ОГРАНИЧЕНИЕМ ЭКСПОРТА ТОВАРОВ ИЗ СТРАН ЕС И ВЕЛИКОБРИТАНИИ

XCS-DMC/XCS-DMP Coded Magnetic Switches, Rectangular

XCS-DM coded magnetic safety switches are designed for monitoring the doors, covers and guards of industrial machines with imprecise guiding and low inertia. These safety switches are ideally suited for machines subjected to frequent washing or liquid spray. They protect the operator by immediately stopping any dangerous movement as soon as the distance between the switch and its magnet is greater than 8mm (5mm for XCS-DMC).
XPS-DM safety modules are specifically designed for monitoring the coded magnetic safety switches. When the XCS-DM safety switch is used in conjunction with the XPS-DM safety relay they offer a certified safety solution for guard monitoring.

Coded magnetic safety switch

Actuation on 3 sides: face to face and face to side
8mm tolerance to misalignment (5mm for XCS-DMC)
LED versions have an LED in series with one N/C giving indication when guard is closed
Coded reed technology - switch cannot be totally defeated by a simple magnet
Rectangular plastic housing
Dimensions: compact: H51 x W16 x D7mm, standard: H88 x W25 x D13mm
Available pre-cabled or with connector on flying lead
IP66/67 protection in accordance with EN/IEC 60529
ROHS compliant

Safety module

Allows multi-switch monitoring to Safety Category 4 solutions in accordance with EN954-1/ISO 13849-1
XPS-DMB can monitor 2 independent sensors and modules, XPS-DME can monitor 6 independent sensors and modules
2 safety outputs and 2 solid state outputs for signalling to the process PLC
LEDs on the front face provide information on the monitoring circuit status
Dimensions: H99 x W22 x D114mm
IP20 protection on terminals and IP40 protection on enclosure, in accordance with EN/IEC 60529

Note

With the appropriate monitoring system and correctly wired these switches can reach safety category 4 conforming to EN/ISO 13849-1, PL e conforming to EN/ISO 13849-1, SIL 3 conforming to EN/IEC 61508.

Standards

IEC 947-1; EN 547-5-1; EN 547-5-3; EN 60204-1; EN 1088 (for Magnetic Switch only)
IEC 204-1; EN 292; EN 60204-1; EN954-1; EN1088 (for Safety Module only)

Техническая спецификация
pdfDatasheet
Безопасные контакты:
1NC/2NO
Встречающиеся стандарты:
BG, CSA, CSA C22.2 No. 14, EN/IEC 60204-1, EN/IEC 60947-5-1, EN/ISO 12100, UL, UL 508
Глубина:
88мм
Диапазон:
Preventa
Длина:
25мм
Категория безопасности:
Category 4 (EN/ISO 13849-1), Category PL e (EN/ISO 13849-1), Category SIL 3 (EN/IEC 61508)
Количество направлений захода:
3
Материал корпуса:
Пластик
Напряжение питания:
24 В пост. тока
Привод в комплекте:
Да
Принцип датчика:
Магнит
Размеры:
25 x 13 x 88 мм
Расстояние переключения:
20 (Tripping) mm, 8 (Operating) mm
Серия:
XCSDMP
Соединение - тип:
M12
Степень защиты IP:
IP67
Тип актуатора:
Кодированный
Тип клеммы:
M12 Conduit
Тип переключателя:
Прямоугольный
Ток питания:
≤100 A
Цвет корпуса:
Красный
Ширина:
13мм
