Keysight EDUX1EMBD Embedded Serial Triggering and Analysis for InfiniiVision EDUX1000 Series Oscilloscopes

The I²C and UART/RS-232 serial decode option for InfiniiVision 1000 X-Series oscilloscopes displays responsive, time-aligned, on-screen decode of Inter-Integrated Circuit (I²C) and UART/RS-232 serial communication buses. Because this capability is hardware-based, it provides the fastest throughput solution for triggering on and analyzing these serial buses. These buses are found in a wide variety of embedded designs.
This measurement application option works with InfiniiVision 1000 X-Series EDUX1002A and EDUX1002G models.

Features and Benefits

The fastest throughput oscilloscope solution for triggering on and analyzing I²C and UART/RS-232 serial buses
Support for the PC serial protocol
On-screen serial decode time-correlated with the serial data waveforms
Protocol trigger and hardware-based protocol decode

Keysight InfiniiVision Series

Keysight InfiniiVision 2000 & 3000 X-Series offers the power of 4 instruments in 1: oscilloscope; logic analyzer; function generator; protocol analyzer. The models are fully upgradable (bandwidth, MSO, WaveGen, memory, measurement applications) to meet future requirements and protect investment.

Keysight 1000 X-Series Digital Oscilloscopes
